Wacker Neuson E16-02

4-20 BA E16 en* 1.0 * E16_10_400.fm
4 Putting into operation
Job site
Work range height A: 120 cm (47 in), E: 50 cm (20 in).
The figures Fig. 98 and Fig. 99 refer to work with a Wacker Neuson
hydraulic hammer.
Information
Working with another attachment can modify the height of the job site.
Fig. 98
E
A
Fig. 99
