9-2 OM ET18/20/24 us 1.3 * et18_20_24t900.fm
9
The machine has about 17 % less output at altitudes over 800 m
(2625 ft) above see level. However, this does not affect
excavator operation (Yanmar 3TNV80F-SSNS1).
Engine ET18 ET20 ET24
Product Yanmar diesel engine
Type 3TNV80F-SSNS1
Design Water-cooled 4 stroke diesel engine
Number of cylinders 3
Displacement 1266 cm
3
(77.3 in
3
)
Nominal bore and
stroke
80 x 84 mm (3.1 x 3.3 in)
Output 12.8 kW/2200 rpm (17.2 hp/2200 rpm)
Max. torque 65.8 Nm/1600 rpm (48.5 ft.lbs./1600 rpm)
Max. engine speed
without load
2375 +/− 50 rpm
Idling speed 1300 +/− 25 rpm
Fuel injection system Indirect injection
Starting aid Glow plug (preheating time 4 seconds)
Fuel tank 24 l (6.3 gal)
Exhaust values
according to
EPA – Tier IV final (from 2012)
