Excavator forces
According to ISO 6015
Ground clearance/ground pressure
ET 18 ET 20 ET 24
Max. tearout force
(short stick)
11.2 kN
(2518 lbf)
12.5 kN
(2810 lbf)
15 kN
(3372 lbf)
Max. tearout force
(long stick)
9.8 kN
(2203 lbf)
11.1 kN
(2495 lbf)
13.3 kN
(2990 lbf)
Max. breakout force
at bucket tooth
18.8 kN
(4226 lbf)
21.8 kN
(4901 lbf)
ET18
ET18 tele-
scopic travel
gear
ET18 VDS/tel-
escopic
travel gear
Ground clearance
210 mm
(8 1/4 in)
170 mm
(6 3/4 in)
170 mm
(6 3/4 in)
Ground pressure
0.31 kg/cm²
(4.4 lbs/in²)
0.30 kg/cm²
(4.3 lbs/in²)
0.32 kg/cm²
(4.6 lbs/in²)
Upper carriage swivel
speed
10 rpm
ET20 telescopic
travel gear
ET 20 VDS/tele-
scopic travel gear
Ground clearance
170 mm
(6 3/4 in)
160 mm
(6 1/4 in)
Ground pressure
0.28 kg/cm²
(4 lbs/in²)
0.29 kg/cm²
4.1 lbs/in²)
Upper carriage swivel
speed
10 rpm
ET24 ET24 VDS
Ground clearance
295 mm
(11 5/8 in)
280 mm
(11 in)
Ground pressure
Canopy/standard travel
gear
0.29 kg/cm²
4.1 lbs/in²)
0.30 kg/cm²
(4.3 lbs/in²)
Upper carriage swivel
speed
10 rpm
