Wacker Neuson ET24 - 3 Introduction; Machine Overview

BA ET18, 20, 24 en* 1.5 * et18_20_24e300.fm 3-1
Introduction 3
3Introduction
3.1 Machine overview
Fig. 2Machine overview
Position Designation
1 Working light on boom
2
Roof lights (option)
3
Lifting eye
4
Rotating beacon (option)
5
Door arrester
6
Engine cover
7
Fuel tank filler inlet
8
Side cover
9
Exhaust pipe
10
Tie-down point for tying down the
machine
11
Stabilizer blade
12
Travel gear
13
Handhold
14
Auxiliary hydraulics
15
Door handle and lock
2
12
1
6
13
11
10
15
2
8
4
5
9
14
10
2
3
3
13
8
10
10
7
Introduction
