ET24 Standard VDS
A Height 2390 mm (7'-10'') 2470 mm (8'-1'')
B1 Upper carriage width 990 mm (39 in)
B2 Travel gear width 1400 mm (55 in)
C Transport length 4030 mm (13'-3'') 3980 mm (13'-1'')
D1 Max. digging depth (short stick) 2500 mm (98 in) 2420 mm (95 in)
D2 Max. digging depth (long stick) 2700 mm (8'-10'') 2620 mm (8'-7'')
E1 Max. vertical digging depth (short stick) 1660 mm (65 in) 1580 mm (62 in)
E2 Max. vertical digging depth (long stick) 1850 mm (73 in) 1770 mm (70 in)
F1 Max. digging height (short stick) 3960 mm (13'-0'') 4040 mm (13'-3'')
F2 Max. digging height (long stick) 4080 mm (13'-5'') 4160 mm (13'-8'')
G1 Max. dump height (short stick) 2750 mm (9'-0'') 2830 mm (9'-3'')
G2 Max. dump height (long stick) 2870 mm (9'-5'') 2950 mm (9'-8'')
H1 Max. reach at ground level (short stick) 4025 mm (13'-2'') 4000 mm (13'-1'')
H2 Max. reach at ground level (long stick) 4220 mm (13'-10'') 4190 mm (13'-9'')
K1 Max. digging radius (short stick) 4150 mm (13'-7'')
K2 Max. digging radius (long stick) 4340 mm (14'-3'')
M Max. boom displacement to bucket center (right-hand side) 520 mm (20 in)
N Max. boom displacement to bucket center (left-hand side) 360 mm (14 in)
O Max. lift height of stabilizer blade over ground 300 mm (12 in) 350 mm (14 in)
P Max. scraping depth of stabilizer blade below ground surface 340 mm (13 in) 320 mm (13 in)
R1 Min. tail end slewing radius 1160 mm (46 in)
R2 Boom swivel radius (center) 1660 mm (65 in)
R3 Boom swivel radius (right) 1580 mm (62 in)
R4 Boom swivel radius (left) limit 1450 mm (57 in)
R5 Max. boom swivel radius (left) 1350 mm (53 in)
S Total running gear length 1840 mm (72 in)
T Running gear length (Turas front idler) 1385 mm (55 in)
V VDS tilt angle - 0 – 15°
W1 Max. tilting angle of boom to the right 48°
W2 Max. tilting angle of boom to the left-hand limit 64°
W3 Max. tilting angle of boom to the left 77°
X Track width 250 mm (10 in)
Y1 Stabilizer blade width 1400 mm (55 in)
Y2
Stabilizer blade width with extension (only telescopic travel
gear)
-
Z Stabilizer blade height 300 mm (12 in)
