OM ET18/20/24 us 1.3 * et18_20_24i400.fm 4-31
4
Designation See page
1. Travel pedals/travel levers
5-14
2. Boom swivel/auxiliary hydraulics pedal (AUX I)
5-29, 5-27
3. Foot-operated pushbutton switch for hydraulic quickhitch (option)
5-35
4. Control lever base
4-18
5. Horn
5-9
6. Control levers
5-12
7. Travel speed changeover
5-1
8. Stabilizer blade/travel gear extension/retraction (option)
5-17, 5-20
9. Display element
4-34
10.Oil flow AUX I rotary switch (proportional controls)
5-22
11.Starter
4-41
12.Right-hand switch panel (cab)
4-32
13.12 Vpower outlet (cab)
--
14.Temperature controller (cab)
5-11
15.Radio (option)
--
16.Switch panel (canopy)
4-32
17.Seat
4-12
18.Throttle
5-1
19.Oil flow AUX II rotary switch (proportional controls)
5-22
20.Changeover for stabilizer blade/travel gear extension/retraction
5-17, 5-20
21.Switch panel on left-hand control lever base
4-32
22.Boom swivel/auxiliary hydraulics pedal changeover (AUX I)
--
23.Powertilt (AUX II) or 3rd control circuit (AUX II) operation (option)
5-33, 5-32
24.Auxiliary hydraulics (AUX I) operation (option) (proportional controls)
5-28
25.Boom swivel pedal (proportional controls)
5-29
