G 3.7A;G/GS 5.6A;GS 8.5V;GS 9.7V Portable Generator Repair
wc_tx000208gb.fm 66
Resistance Values
Note:
Resistance values are very small and require a good quality
meter with the ability to be zeroed out. Using a poor quality meter may
not provide accurate readings.
All figures are approximate values in ohms.
Generator
Model
Main
Winding
Auxiliary
Winding
Rotor
Winding
Choke
Winding
G 2.5A 0.56 1.00 8.12 N/A
G 3.7A 0.66 3.18 12.2 7.50
G 5.6A 0.43 2.16 10.8 7.50
GS 5.6A 0.43 2.16 10.8 7.50
GS 8.5V 0.21 1.62 11.9 7.50
GS 9.7V 0.20 1.74 11.9 7.50
