Portable Generator Repair G 3.7A;G/GS 5.6A;GS 8.5V;GS 9.7V
wc_tx000208gb.fm 57
6.14 Engine Speed (G 3.7A, G 5.6A and GS 5.6A Models)
See Graphic: wc_gr000114
Generators require a fixed engine speed to maintain the correct
voltage. Engine speed is controlled by a governor which automatically
adjusts to varying loads on the engine to maintain a constant speed of
3600 rpm. There is no throttle control.
To set the engine to the proper speed:
Turn the speed adjusting screw (a) in or out to obtain a no-load speed
of 3700 rpm.
CAUTION: Setting the engine speed too high or too low may damage
tools and other appliances attached to the generator.
wc_gr000114
a
