Wacker Neuson PS2 1503 - Operation; Names of Parts

PS (3-Phase) Series Operation
wc_tx000131gb.fm 11
4. Operation
4.1 Names of Parts
See Graphic: wc_gr000327
Note: This diagram shows the parts layout of a typical PS (Three-Phase) model. The external
appearance and the internal construction may vary slightly, depending on your particular model.
Ref. Description Ref. Description
1. Discharge Outlet 8. Lifting Handle
2. Coupling 9. Mechanical seal
3. Oil Housing 10. Oil plug
4. Lubricant 11. Sleeve
5. Impeller 12. Volute
6. Suction cover 13. Strainer
7. Cable Assembly 14. Plate
wc gr000327
7
1
2
8
9
10
11
12
13
14
6
5
4
3
