Maintenance PS (3-Phase) Series
wc_tx000132gb.fm 32
Parts List
See Graphic: wc_gr000338
Disassembly Procedure for 10 HP and 15 HP
Note:
Before disassembling, be sure to drain the lubricant from the
pump.
The breakdown of pump shown is based on the construction of 10 HP
model PS4 7503HH/HF.
5.3.9 Removing the plate (31) and the strainer (30):
After removing the nut (33) and the washer (32) from the bottom,
remove the plate (31) and the strainer (30) from the pump.
5.3.10 Removing the suction cover (25):
After removing the bolt (27), washer (26), stud bolt (29), and the
lockwasher (28), remove the suction cover (25) from the pump.
Ref. Description Ref. Description
1. Bolt 17. O-Ring
2. Lock washer 18. Sealing ring
3. Mechanical seal 19. Shim
AA Screw 20. Impeller
BB Oil Lifter 21. Thread cover
CC Screw 22. Nut
DD Retaining plate 23. Acorn nut
6. O-Ring 24. Gasket
7. Gasket 25. Suction cover
8. Oil casing 26. Lock washer
9. Gasket 27. Bolt
10. Oil plug 28. Lock washer
11. Lock washer 29. Stud bolt
12. Bolt 30. Strainer
13. Sleeve 31. Plate
14. Volute 32. Lock washer
15. Lock washer 33. Nut
16. Bolt
To Next Page
