PT 2/3 /... Maintenance
wc_tx000013gb.fm 26
4.10 Cleaning Fuel Strainer (Wacker)
See Graphic: wc_gr001093
4.10.1 To remove water and dirt, close the fuel lever and remove the fuel
strainer.
4.10.2 Inspect fuel strainer (a) for water and dirt.
4.10.3 After removing dirt and water, wash the fuel cup with kerosene or
gasoline.
4.10.4 Reinstall securely to prevent leakage.
4.11 Fuel Filter (Vanguard)
See Graphic: wc_gr000030
4.11.1 Turn fuel valve off.
4.11.2 Remove bowl (a) gasket (b) and screen (c).
4.11.3 Wash them thoroughly in a nonflammable solvent. Dry them and
reinstall.
4.11.4 Turn fuel valve on and check for leaks.
wc_gr001093
a
