Wacker Neuson PT2A - Engine-PT3 A; PT3 A(I)

wc_td000739en.fm
41
PT2A / PT3A / PT4A Technical Data
10.2 Engine—PT3A / PT3A(I)
1
Net engine power rating per SAE J1349 and ISO 3046. Actual power output may vary due to
conditions of specific use.
Machine PT3A / PT3A(I)
Engine type 4-stroke, overhead valve,
single cylinder
Engine make Honda
Engine model GX 270
Maximum rated power at rated
speed
1
kW (hp) 6.3 (8.5) @ 3600 rpm
Displacement cm³ (in.³) 163 (9.9)
Spark plug (NGK) BPR 6ES
(DENSO) W20EPR-U
Electrode gap mm (in.) 0.7–0.8
(0.028–0.031)
Operating speed rpm 3550
Valve clearance (cold)
intake:
exhaust:
mm (in.) 0.15 ± 0.02 (.006)
0.20 ± 0.02 (.008)
Air cleaner type Dual element
Engine lubrication oil grade SAE 10W30
Service Class SJ, SL
Engine oil capacity L (qt) 1.1 (1.2)
Fuel type Regular unleaded gasoline
Fuel tank capacity L (qt) 5.3 (5.6)
