Technical Data WP 1235A
wpm_td000382gb.fm 14
2.2 Machine Data
2.3 Sound and Vibration Measurements
The required sound specification, Paragraph 1.7.4.f of 89/392/EEC
Machinery Directive, is:
• The guaranteed sound power level (L
WA
) = 108 dB(A).
• The sound pressure level at operator’s location (L
pA
) = 97 dB(A).
These sound values were determined according to ISO 3744 for the
sound power level (L
WA
) and ISO 6081 for the sound pressure level
(L
pA
) at the operator’s location.
The weighted effective acceleration value, determined according to
EN ISO 5349, is approximately 4.5 m/s
2
.
The sound and vibration measurements were obtained with the
machine operating on crushed gravel at nominal engine speed.
WP 1235A
0630016
Plate
Weight
kg (lbs.)
63.35 (139.37)
Exciter Speed
rpm
5800 ± 100
Exciter Lubrication
ml (oz.)
118 ( 4 )
Automatic Transmission Fluid
Dextron III / Mercon or equivalent
Dimensions
mm (in.)
1013 (39.88) x 350 (13.78) x 606 (23.86)
