WP 1540A/AW Technical Data
wc_td000010gb.fm 15
3.2 Machine Data
3.3 Sound and Vibration Specifications
Products are tested for sound pressure level in accordance with EN
ISO 11204. Sound power level is tested in accordance with European
Directive 2000/14/EC - Noise Emission in the Environment by
Equipment for use outdoors.
• The sound pressure level at operator’s location (L
pA
) :
WP 1540A = 97 dB(A)
WP 1540AW = 97 dB(A)
• The guaranteed sound power level (L
WA
) = 108 dB(A).
Products are tested for hand/arm vibration (HAV) level in accordance
with ISO 5349, EN1033, and EN500-4 where applicable.
WP 1540A = 10.8 m/s
2
WP 1540AW = 10.8 m/s
2
WP 1540A/AW
0008060, 0008061, 0009472, 0009545
Plate
Operating Weight
kg (lbs.)
86 (190)
Water Tank Capacity
l (qts.)
10.4 (11.0)
Exciter Speed
rpm / belt
5800
Exciter Lubrication
ml (oz.)
150 (5)
Automatic Transmission Fluid
Dextron III / Mercon or equivalent
Dimensions
mm (in.)
686 (27) x 400 (16) x 965 (38)
