Rear Panel Connections
Connect the Wadia 321 power cord to a
live AC outlet. Refer to information on
the back panel of your 321 to determine
the correct voltage for your unit
DIGITAL AUDIO INPUTS COAXIAL
INPUTS 2 and 1 for components with a
Digital Audio Coaxial Output
DIGITAL AUDIO INPUTS OPTICAL
INPUTS 2 and 1 for components with
a Digital Audio Optical Output
USB DIGITAL AUDIO INPUT
with control signal for connection
to a computer
UNBALANCED AUDIO OUTPUTS analog
audio output signals to a Preamplifier or A/V
Control Center
BALANCED AUDIO OUTPUTS analog
audio output signals to a Preamplifier or
A/V Control Center
