Scope of delivery MagicLock ML22FOX
14
Observe the following instructions when working with electrical parts:
z Only use a diode test lamp or voltmeter to test voltages in electric cables.
Test lamps with an illuminant consume voltages which are too high and
which can damage the vehicle's electronic system.
z When making electrical connections, ensure that:
– They are not kinked or twisted
– They do not rub on edges
– They are not laid in sharp-edged ducts without protection
z Insulate all connections.
z Protect the cables from mechanical wear (for example rubbing against ex-
isting cables) using cable binders or insulating tape.
2 Scope of delivery
No. in
fig. 1
Quan-
tity
Description
Item
number
11Cable set –
2 1 Servo motor for boot lock (2-pin) ML-3602
3 2 Servo motor for door lock (5-pin) ML-3605
4 1 Boot locking unit –
5 1 Controller ML-3061
6 2 Metal hook for door lock servo motor –
7 1 Metal hook for boot lock servo motor –
8 2 Perforated plate for fastening door servo
motor
–
– 1 Fastening material –
ML-22-FOX.book Seite 14 Mittwoch, 15. März 2006 3:40 15
