MagicLock ML22FOX Intended use
15
3 Intended use
The MagicLock ML22FOX (model no. ML-22-FOX) is a central locking
system for fitting in Volkswagen Fox vehicles. It has servo motors which
automatically lock both doors and the boot when the driver or passenger door
is locked.
4 Fitting the central locking system
Removing the door panelling
(Driver and passenger door, see fig. 2, page 3)
➤ Unscrew all the panelling screws.
➤ Remove the retaining ring of the window winder and take off the winder.
➤ Remove the door panelling with a flat object such as a plastic wedge.
Fitting the servo motor in the door
(Driver door see fig. 4, page 3, passenger door see fig. 5, page 3)
➤ Push the plate nuts over the existing holes in the door (see fig. 3,
page 3).
➤ Fasten the servo motor to the perforated plate using two bolts and wash-
ers.
➤ Using two bolts and washers, fasten the perforated plate (fig. 1, Pos. 8,
page 3) to the plate nut.
➤ Attach the metal hook (fig. 1, 6, page 3) to the eyelet of the servo motor
(fig. 1, 3, page 3).
➤ Completely retract the servo motor.
➤ Close the door locking mechanism.
➤ Connect the metal hook to the linkage of the opening mechanism using
the terminal block.
ML-22-FOX.book Seite 15 Mittwoch, 15. März 2006 3:40 15
