Fitting the central locking system MagicLock ML22FOX
16
Preparing the locking unit
(see fig. 6, page 4 to fig. 9, page 4)
➤ Remove the original locking unit in the boot.
➤ Put the matching key into the detached locking unit.
➤ Press the button of the removed locking unit with the lock open.
➤ Release the cylinder by pushing a pointed object into the hole (see fig. 6,
page 4) on the right side of the unit.
➤ Using the key, pull the original cylinder out of the locking unit (see fig. 7,
page 4).
➤ Put the cylinder into the new lock and turn the key back and forth until the
cylinder latches in place.
➤ Place the metal hook (fig. 1, 7, page 3) in the holder of the locking unit
(see fig. 8, page 4).
➤ Tightly close the holder (see fig. 9, page 4) thus fastening the metal
hook to the locking unit.
Attaching the servo motor to the boot
(see fig. 0, page 4 and fig. a, page 4)
➤ Install the new locking unit.
➤ Attach the metal hook of the new locking unit to the eyelet of the servo
motor (see fig. 0, page 4).
➤ Fasten the boot lock servo motor (fig. 1, 2, page 3) using two bolts and
washers to the existing holes in the boot hatch (see fig. b, page 4).
Installing the controller (see fig. b, page 4)
➤ Remove the flap to the left of the steering wheel.
➤ Stick the controller (fig. 1, 5, page 3) under the dashboard.
➤ Plug the cable set (fig. 1, Pos. 1, page 3) into the controller.
➤ Connect the red cable on the cable set (+12 V) to the battery terminal
block in the footwell (inside splashguard).
➤ Connect the black cable on the cable set to a suitable earth point on the
bodywork.
