MagicLock ML22FOX Fitting the central locking system
17
Note
The control wires for the servo motors are bunched together:
– Boot set: blue and green cables
– Passenger door set (long): blue, green, white, brown and red
cables
– Passenger door set (short): blue, green, white, brown and red
cables
Warning
The cables in the doors may not block any moving parts.
➤ Lay the control wires for the door lock servo motors from the interior of the
vehicle via the cable ducts into the doors. (see fig. c, page 5).
➤ Lay the control wires for the boot lock servo motors from the vehicle inte-
rior to the boot. (see fig. d, page 5).
➤ Connect the control wires to the matching colours on the servo motors.
Note
After you have installed the central locking system as described,
check that it works properly. If this test is not successful, adjust
the position of the terminal block on the linkage of the opening
mechanism.
➤ Put all panelling back where it was originally.
