PerfectPower Using the inverter
23
6.3 Connecting the PP402, PP404, PP602 and PP604
!
WARNING!
Do not reverse the polarity. Reversing the polarity of the connec-
tions will cause a great spark and the internal fuses will melt.
➤ To set up the inverter, connect the red cable (fig. 1 4, page 2) to the
positive pole (+) of the battery and the black cable (fig. 1 5, page 2) to
the negative pole (–) of the battery. Make sure the vehicle battery termi-
nals are clean when connecting them.
7 Using the inverter
The main switch (fig. 2 1, page 3) on the back of the device has three posi-
tions:
ON: the inverter is switched on.
OFF: the inverter is switched off.
REMOTE: the inverter is switched on and off by an external switch.
➤ Connect your power consuming device, to the socket (fig. 1 1, page 2)
of the inverter.
Switching on at the device
➤ Set the main switch (fig. 2 1, page 3) to “ON”.
✓ The green LED (fig. 1 3, page 2) lights up.
Switching off the device
➤ Set the main switch (fig. 2 1, page 3) to “OFF”.
✓ The green LED (fig. 1 3, page 2) goes out.
Switching on with an external device
You can also switch the inverter on and off with an external switch.
➤ Set the main switch (fig. 2 1, page 3) to “REMOTE”.
➤ Connect the external switch to the remote port (fig. 2 4, page 3) in ac-
cordance with the following circuit diagrams:
– External switch, voltage supply from the inverter: fig. 3, page 4
✓ If the inverter is switched on via an external switch, the green LED
(fig. 1 3, page 2) lights up.
