FURNO 700 · FURNO 750
6
EN
Features Fig. 1
1) Control panel - temperature and fan speed
2) Hanging hook
3) Cordset with integrated stabilizers (removable with tool)
4) Rear stabilizer ns (upright standing)
5) Side bars to prevent nozzle touching surface
6) Nozzle Heat Shield
Fig. 1
5
2
6
3
4
7
1
Removing the barrel cover
The barrel cover can be removed when working in hard to reach
locations. BE CAREFUL OF THE NOZZLE. Increased risk of burning
exists when working without the barrel cover. To remove the barrel
cover, use a small at head scew driver to lift tab (Fig.1, 7) over raised
area.
Attaching and Detaching the Cordset
The cordset (Fig. 2, 1) for the Heat Gun is delivered detached from
the gun (Fig. 2, 2). To attach, line up the cord with the socket on the
handle of the gun and press rmly together until you hear a click. The
cord set does not need to be removed. If required to detach, insert a
small at head screwdriver (Fig. 2, 3) or, similar tool into the hole as
shown. Firmly push the screwdriver and tilt it upward (4) towards the
handle to release the cordset. Firmly pull the cordset away from the
gun.
Fig. 2
Attaching Detaching
1
2
3
4
