WAGNER flexio 690 User Manual

English
© Wagner Spray Tech - All Rights Reserved 7
Assembly (continued)
4. Align the arrow on the spray gun with the “unlock”
symbol on the spray gun handle.
5. Insert and twist the spray gun into the handle toward the
“lock” symbol on the spray gun handle.
The tab below the trigger will lock the two pieces into
place.
6. Insert the air hose tightly into the connection on the
spray handle. The connection can be positioned as
desired.
7. Insert the air hose tightly into the connection into the
turbine. The connections can be positioned as desired.
4
5
6
7

WAGNER flexio 690 Specifications

General

Adjustable Settings	Yes
Weight	4.5 kg
Material Compatibility	paints, stains, varnishes
Material Throughput	0.8 l/min
Power Source	Electric
