HC 35 E • HC 45 E • HC 55 E 51
g
Accessories and spare parts
HC 35 E HC 45 E HC 45 E-SSP HC 55 E HC 55 E-SSP
Item Order No. Order No. Order No. Order No. Order No. Description
2 –––––––– –––––––– –––––––– –––––––– –––––––– High-pressure hoses and connection
sockets, see under 11. Standard
equipment HC units
3 0256 343 0256 343 –––––––– –––––––– –––––––– Double socket NPSM 3/8 inch
(for hose extension)
–––––––– –––––––– 3202 901 3202 901 3202 901 Double socket 1/2 inch
(for hose extension)
–––––––– –––––––– 9985 781 9985 781 9985 781 Double socket 3/4 inch
(for hose extension)
4 0268 905 0268 905 0268 905 0268 905 0268 905 Texture tip set 4, 6, 8, 10 mm
5 0258 202 0258 202 0258 202 0258 202 0258 202 Spray head for working
with Airless filler (sprinkle texture)
with air support
0258 720 0258 720 0258 720 0258 720 0258 720 Sprinkle texture set:
Spray head, texture tip set,
tip-cleaning needle and air hose
DN 9 mm, 15 m with rapid action
coupling (no. fig.)
6 0345 010 0345 010 0345 010 0345 010 0345 010 In-line roller IR-100
7 –––––––– 0349 907 0349 907 0349 907 0349 907 Container suction system,
hose diameter 50 mm
–––––––– –––––––– 0349 908 –––––––– 0349 908 Container suction system,
hose diameter 75 mm for Airless
spray primer
8 –––––––– 0258 712 –––––––– 0258 712 –––––––– Dispersion system
9 –––––––– 0258 715 –––––––– 0258 715 –––––––– Plaster system
10 –––––––– –––––––– 0349 910 –––––––– 0349 910 Container – Spacspray (plaster)
12.2 Spare parts list for the material feed pump HC 35 E
(spare parts diagram, see page 121)
Item Order No. Description
1 0349 473 Cover (2)
2 0349 472 Screw (2)
3 0349 406*(**) Spiral ring
4 0349 506 Connection pin
5 0349 612 Adapter
6 0349 238*(**) Packing, complete (2)
7 0349 498 Conical spring
8 0349 507* Piston rod
9 0349 493 Spring plate
10 0349 505*(**) Bushing
11 0349 504 Pressure spring
13 0349 519*(**) Ball
Item Order No. Description
14 0349 500 Outlet valve seat
15 0349 503*(**) O-ring (2)
16 0349 508* Cylinder
17 0349 502*(**) O-ring
18 0349 501 Ball guide
19 0349 509*(**) Ball
21 0349 518 Inlet valve housing
22 0349 517 Suction tube
23 0349 602 Filter, 10 meshes
0349 716* Service set: material feed pump
0349 717** Service set: valves and packings
9992 504 250 ml separating oil (Mesamoll)
