54 HC 35 E • HC 45 E • HC 55 E
g
Accessories and spare parts
HC 45 E
HC 45 E-SSP
HC 55 E
HC 35 E HC 55 E-SSP
Item Order No. Order No. Description
1 0349 358 0349 358 Pressure hose
2 0349 465 0349 465 Angle
3 0349 339 0349 339 Connection nipple
4 0349 337 0349 337 Tube
5 0349 338 0349 338 Hose clamp
6 0349 340 0349 340 Angle
7 0349 341 0349 341 Pressure regulating knob
8 0349 490 0349 455 Hydraulic oil pump
9 0349 456 0349 456 Feather key
10 0349 345 0349 345 Securing screw
11 0349 483 0349 344 Pulley
12 0349 360 0349 360 O-ring
13 0349 302 0349 302 Hexagonal bold (8)
14 0349 303 0349 303 Lock washer (10)
15 0349 457 0349 457 Oil tank cover
16 0349 348 0349 348 Countersunk bolt (2)
17 0349 347 0349 347 Washer (2)
18 0349 349 0349 349 Screw (2)
19 0349 350 0349 350 Seal
20 0349 374 0349 374 Tightening nut
23 0349 351 0349 351 Double nipple
24 0349 352 0349 352 Angle
25 0349 353 0349 353 Filter
26 0349 458 0349 458 Securing nut (2)
27 0254 426 0254 426 Washer (5)
28 0349 480 0349 480 Hexagonal bolt (3)
29 0349 484 0349 484 Sealing screw
30 0349 302 0349 302 Hexagonal bolt
31 0349 485 0349 485 Hydraulic oil tank
32 0349 371 0349 371 Distance washer
33 0349 370 0349 370 Bolt
34 0349 369 0349 369 Cap nut
35 0349 368 0349 368 Wing screw
36 0349 672 0349 672 Return hose
37 0349 465 0349 465 Angle 45°
38 0349 463 0349 463 Adapter
39 0349 361 0349 361 Earthing bar
40 0349 373 0349 373 Bypass valve
41 0349 468 0349 468 Filter
42 0349 467 0349 467 Filler neck
43 0349 614 0349 614 Oil measuring stick
44 0349 521 0349 521 Ball valve
12.6 Spare parts list for the hydraulic system
(spare parts diagram, see page 124)
