WAGNER HC 940

HC920•HC940•HC960 41
GB
Starting operation
2
1
4.3 High-pressure hose, spray gun and
separating oil
 1. Screwthehigh-pressurehose(g.12,item1)ontothe
hose connection (2).
 2. ScrewHC940-SSP•HC960andHC960-SSPdouble
socket (3) into the high-pressure hose.
Screw on hose whip (4).
3. Screw connection socket (5) to the spray gun (6).
4. Screw spray gun with selected tip to the high-pressure
hose or hose whip (4), depending on the model.
5. Tighten union nuts at high-pressure hose and, depending
on the model, at the hose whip to prevent coating material
from leaking.
2
11
5
6
4
1
3
 6. FillinEasyGlide(g.13).Donotllintoomuchseparating
oil, i.e. ensure that no separating oil drips into the coating
material container.
Attention
EasyGlide prevents increased wear and tear to
the packings.
