500-72203-001 Rev. H Page 7 of 15
SPRING REPLACEMENT
When cleaning under the springs, remove the springs. NEVER lift up on the springs
this will distort the metal. If the springs should become damaged in any way replace
them in pairs. See Replacement Parts section for Part Numbers which may be
purchased from the factory or through your distributor.
Symbol Description
A REMOVE SCREWS.
REPLACE SPRINGS.
LABEL # 7 35 - 72 200 -00 1 REV. A
IMPORTANT!
CLEAN
INSTRUMENT
DAILY.
NEVER
USE SOLVENT
OF ANY
KIND FOR CLEANING.
MAINTENANCE OF
THE
PROBE CONSISTS
OF CLEANING
THE PROBE
ASSEMBLY
PERI ODICALLY
WI TH MILD
DETERGENT
CLEANING
SOLUTION
AND
A SOFT RAG.
SCRAPE
EXCESS
PI TCH
OFF
WI TH
A
FLAT BLADED
INSTRUMENT
SUCH
AS
A
CHISEL
OR
PUTTY
KNIF E,
BEING
CAREFUL
NOT TO DIG
INTO THE PROBE.
NEVER
SOAK
OR
SUBMERGE
INSTRUMENT IN
ANY
LIQUID
