500-72203-001 Rev. H Page 8 of 15
HINGE REPAIR/REPLACEMENT
If the hinge becomes stretched, removal of the hinge screws and reseating of the
hinge is all that is normally necessary. (Waiting for 30 minutes with the hinge
removed will allow the hinge material to relax). If the hinge is severely distorted, see
Replacement Parts section for Part Numbers which may be purchased from the
factory or through your distributor.
Symbol Description
A REMOVE HINGE SCREWS, AND RESEAT OR REPLACE HINGE.
STORAGE
The stack probe should be cleaned and stored in a cool dry environment.
LABEL # 7 35 - 72 200 -00 1 REV. A
IMPORTANT!
CLEAN INSTRUMENT DAILY.
NEVER U SE SOLVENT OF
ANY KIND
FOR CLEANING.
MAINTENANCE OF
THEPROBE CONSISTS
OF
CLEANINGTHE PROBE
ASSEMBLY PERI ODICALLY
WI TH MILD
DETERGENT
CLEANING
SOLUTION AND
A SOFT RAG.
SCRAPE EXCESS PITCH
OFF WI TH
AFLAT
BLADED
INSTRUMENT
SUCH ASACHISEL OR PUTTY
KNIF E, BEING
CAREFUL
NOT TO DIG
INTO THE PROBE.
NEVER SOAK OR
SUBMERGE
INSTRUMENT
INANY LIQUID
