500-72203-001 Rev. H Page 11 of 15
Step 5. Connect Replacement cord to coupler. Ensure latch clicks into detent.
Step 6. Carefully stow service loop and reassemble handle. See Step 1 for screw
locations.
REPAIR SERVICE
In the event of damage or failure, the Probe Head can be removed from the
extrusion.
You have the option of sending in your entire Stack Probe or the Stack Probe Head.
Your equipment will be repaired, calibrated, and returned promptly.
