82
OPERATING MANUAL
VERSION 01/2013 ORDER NUMBER DOC 2333538
11.4.4 FLUID SECTIONS 150 CM
Fluid sections spare parts list
Designation No. No. No.
1 1 Fluid section 2329650 2329664 2329652
2 1 Tube 368552
3 1 Cylinder 368553
4 1 Inlet housing 150 2327888
5
1 Piston 368555
6 1 Valve screw 368506
7 1 Ball guide, inlet 368507
8 1 Connection ange 368551
9
1 Valve seat, inlet 368509
10 1 Valve seat, outlet 368510
11 1 Snap ring ange 368561
12 2 Snap ring half 368512
13 1 Securing ring 368513
16 1 Support ring 368516
17 1 Pressure ring 367519
18 1 Support ring 368518
19 1 Pressure ring 368519
100
1 Packing PE/TG complete (small) 367991
101 1 Packing PE/T complete (small) 367992
102 1 Packing PE/L complete (small) 367993
Wearing part
included in service set
Special accessories
Incorrect maintenance/repair!
Risk of injury and equipment.
Have repairs and part replacements be carried out only by
specially trained sta or a WAGNER service center.
Before all work on the device and in the event of work
interruptions:
- Switch o the energy/compressed air supply.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Always follow the operating and service instructions at all times
when carrying out work.
WARNING
