English
6
Remote Suction
Hose Setup
(optional)
Start
1. Remove the cup -
See steps 1-3, previous page.
3. Attach the housing to the bottom of the
sprayer as shown.
Rotate the housing until it clicks into place.
2. Twist and remove the suction tube and
lter assembly.
4. Attach lid to paint container.
Push hoses through the holes in the lid
and down to the bottom of the material
container.
Recommended for
medium to large jobs
Note: A 75% duty cycle is recommended when
spraying with the remote suction hoses. For
example, trigger the gun for 15 seconds, and
then allow the gun to remain idle (untriggered)
for 5 seconds.
IMPORTANT: Avoid running the container
dry. An empty container will allow air to
get sucked into the sprayer, which leads to
globbing and spitting.
IMPORTANT: Always make sure the tip nut
is tightened securely prior to spraying.
Note: The Low Cup Level Indicator (if
equipped, see page 8) are not applicable when
using the remote suction hoses.
1
3
2
4
To Next Page
