GB
25
W 570 Flexio
•
Never open the device yourself in order to carry out repairs in the electrical system!
•
The units may only be used with a functional valve. If paints rises in the ventilating
hose (Fig. 1, item 15) do not operate the unit further! Dismantle and clean the
ventilating hose, valve and diaphragm and replace the diaphragm if necessary.
•
Do not lay the spray gun.
With original WAGNER accessories and spare parts, you have the guarantee that
all safety regulations are fullled.
4. Description/ Scope of delivery
Description/ Scope of delivery (Fig. 1)
1) Nozzle 2) Air cap (to set the working direction)
3) Union nut 4) Spray jet width adjustment
5) Wall Extra I-Spray spray attachment 6) Material volume adjustment
7) Air volume control 8) Spray gun rear part
9) Air lter cover 10) ON/OFF switch (located on both sides)
11) Trigger 12) Mains lead
13) Container 14) Valve
15) Ventilating hose 16) Stirring rod
17) Feed hopper (2 pcs.) 18) Practice poster
19) Standard spray attachment 20) Replacement nozzle seal (Standard
spray attachment)*
21) Lubricating grease* 22) Lubricating grease*
* This is inside the container: remove it before starting operations!
5. Field of application
Many dierent coating substances can be processed with the W 575.
A dierent spray attachment must be used, depending on the coating substance:
Coating Materials Spray attachment
Low-viscosity coating substances:
Water- and solvent-based paints, nishes,
primers, 2-component paints, clear
nishes, automotive nishes, staining
sealers and wood sealer-preservatives.
All coating materials with the red Perfect
Spray logo
Standard
