33
W 590 Flexio
EN
1) Press both locks (Fig. 22, 1) and remove the lter cover.
2) Remove the air lter (2) and replace depending on contamination.
3) Click the lter cover in place again.
Ventilating hose / Valve
1) Pull the ventilating hose (Fig. 15, 1) at the top from the gun body. Screw o the valve
cover (2). Remove the diaphragm (3). Carefully clean all parts or replace in the
event of damage.
2) Place the diaphragm (Fig. 15, 3) with the pin facing upwards on the bottom section
of the valve. Also see the marking on the gun body.
3) Place on the valve cover (Fig. 15, 2) and screw it closed.
4) Place the ventilating hose (Fig. 15, 1) on the valve cover and on the nipple at the gun
body.
22. Spare Parts
Spare Parts List Wall Extra I-Spray spray attachment (Fig. 23)
Pos. Designation Order No.
Wall Extra I-Spray spray attachment complete with 1300 ml
container
2361 746
1 Air cap 2382 753
2 Union nut and nozzle 2382 751
3 O-ring of spray attachment 2362 875
4 Ventilating hose, valve cover, diaphragm 2382 754
5 Suction tube 2389 021
6 Container seal 2389 023
7 Container with cover 1300 ml (only for Wall Extra I-Spray spray
attachment)
2305 155
Spare Parts List Standard spray attachment (Fig. 24)
Pos. Designation Order No.
Standard spray attachment complete with 800 ml container 2361 730
1 Union nut 2362 873
2 Air cap 2362 877
3 Nozzle 2362 878
4 Nozzle seal 0417 706
5 O-ring of spray attachment 2362 875
6 Ventilating hose, valve cover, diaphragm 2304 027
7 Suction tube (no marking or R)*
Suction tube (marking AR or AU)*
2362 876
2367 410
8 Container seal (no marking or R)*
Container seal (marking AR or AU)*
2323 039
2370 527

WAGNER W 590 Specifications

General

Power	630 W
Max. Viscosity	80 DIN
Power Consumption	630 W
Max. Power Consumption	630 W
Voltage	230 V
Frequency	50 Hz
Container Capacity	1300 ml
Container Volume	1.3 L
