750-461, (/xxx-xxx) [2 AI Pt100/ RTD] • 19
Process Image
WAGO-I/O-SYSTEM 750
I/O Modules
2.1.2.7.3 I/O Modules for Resistance Measuring
Resistance measuring
750-461/000-002 Resistance measuring,
Measuring range: 10 Ω ... 1.2 kΩ
750-461/000-007 Resistance measuring,
Measuring range: 10 Ω ... 5.0 kΩ
The measured values are sent out directly when measuring the resistance.
Using the 750-461/000-002 module with measuring range from 10 Ω to
1.2 kΩ, the resolution is 1 digit per 0.1 Ω.
Using the 750-461/000-007 module with measuring range from 10 Ω to
5.0 kΩ, the resolution is 1 digit per 0.5 Ω.
Resistance measurement is only possible in 2-wire connection technology.
The analog input module transmits 16-bit measured values per channel as well
as 8 optional status bits to the coupler/controller.
750-461/000-002 (10 " ... 1,2 k")
Resistance Numerical value
Status-
byte
LED
Error
" binary hex. dec. hex. AI 1,2
0 '1110.1100.0000.0000' 0xEC00 -5120 0x00 off
10 '0000.0000.0110.0100' 0x0064 100 0x00 off
100 '0000.0011.1110.1000' 0x03E8 1000 0x00 off
200 '0000.0111.1101.0000' 0x07D0 2000 0x00 off
300 '0000.1011.1011.1000' 0x0BB8 3000 0x00 off
400 '0000.1111.1010.0000' 0x0FA0 4000 0x00 off
500 '0001.0011.1000.1000' 0x1388 5000 0x00 off
750 '0001.1101.0100.1100' 0x1D4C 7500 0x00 off
1000 '0010.0111.0001.0000' 0x2710 10000 0x00 off
1200 '0010.1110.1110.0000' 0x2EE0 12000 0x00 off
>ca.1200 '0010.0001.0011.0100' 0x2134 8500 0x42 on
Values marked with "ca." are not calibrated.
750-461/000-007 (10 " ... 5 k")
Resistance Numerical value
Status-
byte
LED
Error
" binary
1)
hex. dec. hex. AI 1,2
0 '1110.1100.0000.0000' 0xEC00 -5120 0x00 off
10 '0000.0000.0001.0100' 0x0014 20 0x00 off
100 '0000.0000.1100.1000' 0x00C8 200 0x00 off
200 '0000.0001.1001.0000' 0x0190 400 0x00 off
300 '0000.0010.0101.1000' 0x0258 600 0x00 off
1000 '0000.0111.1101.0000' 0x07D0 2000 0x00 off
2000 '0000.1111.1010.0000' 0x0FA0 4000 0x00 off
3000 '0001.0111.0111.0000' 0x1770 6000 0x00 off
4000 '0001.1111.0100.0000' 0x1F40 8000 0x00 off
5000 '0010.0111.0001.0000' 0x2710 10000 0x00 off
>ca.5000 '0010.0111.0001.0000' 0x2710 10000 0x42 on
Values marked with "ca." are not calibrated.
