PART IDENTIFICATION:
01 - UPPER HEADBOARD / FOOTBOARD POST (2PCS)
02 - UPPER HEADBOARD / FOOTBOARD POST (1PC)
03 - UPPER HEADBOARD / FOOTBOARD POST (1PC)
04 - LOWER HEADBOARD / FOOTBOARD POST (2 PCS)
05 - LOWER HEADBOARD / FOOTBOARD POST (2 PCS)
06 - UPPER RAIL (3 PCS)
07 - UPPER RAIL (1 PC)
08 - MIDDLE RAIL (4 PCS)
09 - LOWER RAIL (4 PCS)
10 - LEFT LADDER RAIL (1 PC)
11 - RIGHT LADDER RAIL (1 PC)
12 - FRONT SIDE RAIL (2 PCS)
13 - LONG GUARD RAIL (2 PCS)
14 - BACK SIDE RAIL (2 PCS)
15 - REINFORCEMENT CROSSBAR (2 PCS)
16 - JOINT SLAT (26 PCS)
17 - SHORT GUARD RAIL (2 PCS)
19 - LADDER STEP (4 PCS)
