Section 9: Technical Data
Dryer Sizing Table
Dryer
Model
Unit
Inlet Flow Rate
Dryer
Config.
Dimension (mm) Weight Dimension (inches)
Dryer
Pre
FIlter
Nm³/h SCFM A B C Kg lb A B C
PD004
3
/ 8 7 4 simplex 490 351 92 13 28.7 19 13.8 3.6 PD004 A038
PD006
3
/ 8 10 6 simplex 549 351 92 14 30.9 22 13.8 3.6 PD006 A038
PD008
3
/ 8 14 8 simplex 609 351 92 15 33.1 24 13.8 3.6 PD008 A038
PD010
3
/ 8 17 10 simplex 679 351 92 17 36.4 27 13.8 3.6 PD010 A038
PD015
3
/ 8 25 15 simplex 859 351 92 20 43.0 34 13.8 3.6 PD015 A038
PD025
3
/ 8 42 25 simplex 1109 351 92 24 52.9 44 13.8 3.6 PD025 A038
PD035
3
/ 8 59 35 simplex 1504 531 92 31 68.4 59 13.8 3.6 PD035 A038
PD045 ¾ 76 45 simplex 768 530 272 53 116.9 30 20.9 10.7 PD045 A038
PD055 ¾ 93 55 simplex 868 530 272 59 130.1 34 20.9 10.7 PD055 A078
PD065 ¾ 110 65 simplex 968 530 272 64 141.1 38 20.9 10.7 PD065 A078
PD085 1 144 85 simplex 1170 530 272 75 165.4 46 20.9 10.7 PD085 A108
PD105 1 178 105 simplex 1480 530 272 91 200.7 58 20.9 10.7 PD105 A108
PD135 1¼ 229 135 simplex 1680 530 272 102 224.9 66 20.9 10.7 PD135 A128
PD175 1¼ 297 175 simplex 2080 530 272 123 271.2 82 20.9 10.7 PD175 A128
PD215 1½ 365 215 duplex 1488 530 459 172 379.3 59 20.9 18.1 PD215 A158
PD275 1½ 467 275 duplex 1688 530 459 192 423.4 66 20.9 18.1 PD275 A158
PD365 1½ 620 365 duplex 2098 530 483 232 511.6 83 20.9 19.0 PD365 A159
Pressure Correction Factor (PCF)
Operating Pressure
barg
4 5 6 7 8 9 10 11 12 13 14 15 16
psig
58 73 87 102 116 131 145 160 174 189 203 218 232
PCF*
0.62 0.75 0.87 1.00 1.12 1.25 1.37 1.50 1.62 1.75 1.87 2.00 2.12
*Always use the pressure correction factor (PCF) closest to actual inlet pressure condition
Temperature Correction Factor (TCF)
Temperature
°C
20 25 30 35 40 45 50
°F
68 77 86 95 104 113 122
TCF
1.07 1.06 1.04 1.00 0.88 0.67 0.55
Dewpoint Correction Factor (DCF)
Temperature
°C
-40 -70
°F
-40 -94
DCF
1.0 0.7
