Walker A21 Hi-Dump - Page 23

20
Maintenance Instructions
Ident Lubrication No.
No. Location Type Places
1 Hi-Dump
®
Catcher Frame Grease 2
2 LH/RH Rear Pivots Grease 2
3 Catcher Pivot Arm Grease 1
4 Hydraulic Power Unit Oil 1
A21 Lubrication Points Diagram
1
3
2
4
2
