Specications
5
MODEL B23i
DIMENSIONS (Tractor and Mower)
Length in. (cm)
Tractor Only
58-1/4 (148) Tail Wheels Forward - Muffler is Most Rear Point
Tractor Wheel Base
40 (102)
Tractor with Tilted Deck
(Approximate)
72 (183)
Tractor with 48" Mulch Deck
(DM48-2)
90-3/4 (230)
Width in. (cm)
Tractor Only (Outside Tire)
38 (97)
Tractor with 48" Mulch Deck
(DM48-2)
49 (125)
Height in. (cm)
Tractor
39-1/2 (100)
Weight lb (kg)
Tractor Only
594 (269) With PTO Quick Disconnect Coupling
Tractor with 48" Mulch Deck
(DM48-2)
800 (363)
DRIVE BELTS
Engine PTO Walker P/N 4230-1
Ground Drive
Walker P/N 4230-2
SEAT Contour-Molded, with Nylon Backed Vinyl Cover and
Integral Foam Cushion
FRAME/BODY CONSTRUCTION
Frame All Welded Unitized Steel Chassis
Body 14 Gauge Steel
Deck 11 Gauge Steel
NOTE: The manufacturer reserves the right to make changes in specifications shown herein at any time
without notice or obligation. The specifications listed are for a standard configuration tractor, and may
change with the addition of optional equipment.
