Walker WP3270LCD User Manual

English - 37 -
Appendix C: AV and HDMI Signal
Compatibility (Input Signal Types)
Source
Supported Signals
Available
EXT-1
(SCART 1)
PAL 50/60 O
NTSC 60 O
RGB 50 O
RGB 60 O
EXT-2
(SCART-2)
PAL 50/60 O
NTSC 60 O
RGB 50 X
RGB 60 X
FAV
(SIDE AV)
PAL 50/60 O
NTSC 60 O
YPbPr
480I 60Hz O
480P 60Hz O
576I 50Hz O
576P 50Hz O
720P 50Hz O
720P 60Hz O
1080I 50Hz O
1080I 60Hz O
1080P 50Hz O
1080P 60Hz O
HDMI1
HDMI2
HDMI3
HDMI4
480I 60Hz O
480P 60Hz O
576I 50Hz O
576P 50Hz O
720P 50Hz O
720P 60Hz O
1080I 50Hz O
1080I 60Hz O
1080P 50Hz O
1080P 60Hz O
1080P 24Hz O
(X: Not Available, O: Available)
In some cases a signal on the LCD TV may not be displayed
properly. The problem may be an inconsistency with standards
from the source equipment (DVD, Set-top box, etc. ). If you
do experience such a problem please contact your dealer and
also the manufacturer of the source equipment.
Appendix B: PC Input Typical
Display Modes
The display has a maximum resolution of 1920 x 1080.
The following table is an illustration of some of the
typical video display modes. Your TV may not support
different resolutions. Supported resolution modes are
listed below. If you switch your PC to an unsupported
mode, a warning OSD will appear on the screen.
Index
Resolution
Frequency
1
640x480p - VGA 59
2
640x480p - VGA 72
3
640x480p - VGA 75
4
640x480p - VGA 85
5
800x600p - SVGA 56
6
800x600p - SVGA 60
7
800x600p - SVGA 72
8
800x600p - SVGA 75
9
800x600p - SVGA 85
10
1024x768p - XGA 60
11
1024x768p - XGA 60
12
1024x768p - XGA 66
13
1024x768p - XGA 70
14
1024x768p - XGA 75
15
1024x768p - XGA 84
16
1152x864p 75
17
1280x1024p - SXGA 75
18
1280x1024p - SXGA 85
19
1280x1024p - SXGA 60
20
1280x768p - WXGA 59
21
1280x768p - WXGA 59
22
1280x768p - WXGA 74
23
1280x768p - WXGA 84
24
1280x960 - WXGA 60
25
1280x960p - WXGA 85
26
1360x768p - WXGA 60
27
1360x768p - WXGA 60
28
1400x1050p - SXGA+ 74
29
1600x1200p - UXGA 60
30
1920x1080p 59
