PULSAR - installation guide en 8
PRODUCT DESCRIPTION 2/3
GENERAL
Model name Pulsar Type 2
Mode Mode 3
Overall dimensions (w/o connector) 160x160x90mm
Weight
Operating temperature
Storage temperature
CE Marking
SPECIFICATIONS
Max. power 22 kW three phase
Input voltage 230VAC (1P), 400V AC (3P) ± 10%
Max. current 32A, cable size up to 5x6mm²
Nominal frequency 50Hz
Protection I
Degree of protection IP54
Overvoltage category CAT III
INTERFACE
Pulsar Type 1
Mode 3
160x160x90mm
Between 25ºC and 45ºC
Between -40ºC and 70ºC
IEC61851-1 , IEC61851-22
7,4kW one phase
230V, AC ± 10%
32A, cable size up to 5x6mm²
50Hz
I
IP54
CAT III
IEC61851-1 , IEC61851-22
MECHANICAL
Installation
Cooling
Wall mount
Natural
Wall mount
Natural
INFORMATION SUMMARY
3,0-4,0 Kg depending on cable length 3,0-4,0 Kg depending on cable length
Between 25ºC and 45ºC
Between -40ºC and 70ºC
Halo LED Green Ready State
Tuquoise Connected State
Blue Charging State
Red Error State
Green Ready State
Tuquoise Connected State
Blue Charging State
Red Error State
