4�7�4 BX72S / 102S HOOD DEFLECTOR:
The discharge chute is equipped with a hood deec-
tor on the end of the chute to direct the chips exactly
where desired. The deector is held in position by a
slotted position handle.
1. Grasp the handle and lift slightly to clear the
handle cogs
2. Move the deector with the handle as required
3. Lock the deector into position by lowering the
handle into one of the slots.
4�7�2 BX32S HOOD DEFLECTOR:
The discharge chute is equipped with a hood
deector on the end of the chute to direct the chips
exactly where desired. The deector is held in
place by clamping bolts on each side.
1. Loosen the clamping bolts on each side.
2. Move the deector to desired position and
tighten the manual clamps.
Manual Clamp
Deector
4�7�3 BX52S HOOD DEFLECTOR:
The discharge chute is equipped with a spring
tensioned hood deector on the end of the chute to
direct the chips exactly where desired.
1. Lift and push forward the adjustor grip handle
and move the deector into position as required.
2. Lock the deector into position by pulling back
and down.
Deector
Adjuster
Deector
