WAMGROUP SILOTOP R03 Series - Technical Specifications and Equipment Description; Equipment Overview; Main Component Identification

SILOTOP R03
3.0 TECHNICAL INFORMATION
2
FIL.100.--.M.EN Issue: A2
06.12
10
SILOTOP
®
LVDF\OLQGULFDOO\VKDSHGGXVWFROOHFWRUIRUYHQWLQJRISQHXPDWLFDOO\¿OOHGVLORV
The stainless steel body contains vertically mounted POLYPLEAT
®
¿OWHUHOHPHQWV7KHDLUMHWFOHDQLQJV\VWHP
is integrated in the hinged weather protection cover.
'XVWVHSDUDWHGIURPWKHDLUÀRZE\POLYPLEAT
®
drops back into the silo after an integrated automatic re-
YHUVHDLUMHWFOHDQLQJV\VWHPLQVLGHWKHZHDWKHUSURWHFWLRQFRYHUKDVUHPRYHGLWIURPWKH¿OWHUHOHPHQWV
SILOTOP
®
is designed for being integrated with other systems in the context of a plant in order to obtain a
FOHDUO\GH¿QHGDSSOLFDWLRQ
3.1 General description of the equipment
3.2 Main components
1) Filter body
2) Seal frame
3) Air tank
4) Solenoid valves
5) Blow pipes
6) Condensation drain cock
7) Filter cover
8) POLYPLEAT
®
¿OWHUHOHPHQWV
9)
Electronic timer
