Page 3WAMPLER METAVERSE
OVERVIEW
MIDI Input /
Output:
Use 3.5mm TRS
Trails Slide Switch:
True Bypass (left),
Trails (right)
Power:
9V DC Only
130mA
Expression:
1/4” Expression Pedal Input
Program Selector:
ANLG - Analog delay
WET - Modulated analog
BBD - ‘Bucket Brigade’ delay
JET - Analog anger delay
DOC - ‘The Doctor’
FTE - ‘Faux Tape Echo’
ETH - ‘Ethereal’
MOD - Digital anger delay
SPC - Space echo
TAPE - Multi-head tape echo
DIGI - Digital delay
Output Jacks:
Mono or Stereo
Primary Controls:
Delay: sets delay time
between 25ms (CCW) and
2000ms (CW)
Mod: sets modulation depth
(CCW lowest, CW highest)Alt:
sets modulation rate for all
effects
Feedback: sets delay feedback
(CCW lowest, CW highest)
Alt: (TAPE) selects head
combination
Alt: (ETH) selects Ethereal
mode
Mix: sets dry signal and delay
signal mix CCW for 0% and
CW for 100%
• 0% = dry 100% + wet 0%,
• 75% = dry 100% + wet 100%
• 100% = dry 0% + wet 100%
Alt: sets total output level for
all effects (0% = -6dB, 50% =
0dB, 100% = +6dB)
Tone: sets delay tone
Alt: sets modulation feedback
for JET and MOD programs
Preset Switch:
Increments Preset, Hold to initiate save
Alt: select subdivision (when bypass switch is held)
Preset LEDs:
Indicates Preset number 1-8
Alt: indicates current subdivision
Alt: (TAPE) indicates TAPE head combination
Alt: (ETH) indicates Ethereal mode
Bypass Switch / LED:
Turns Delay effect on/off
Alt: hold down to access
alternate functions on knobs
(subdivisions, mod rate, output
volume, TAPE mode, ETH
mode, anger feedback) LED
will turn red
Tap Tempo Switch / LED :
• Trigger tap tempo to set delay
time (LED is blue)
• Increment Preset (LED is green)
• Hold Tap Tempo Switch for 1
second to toggle between modes
• Pressing tap tempo switch will
exit Preset save mode
Input Jacks:
Mono or Stereo
