Wangen KL 30 Series User Manual

Instruction Handbook KL
Chapter 2
BA KL V11 en 10/2014 page 2-1
Set-up and General Description 2
2.1 Pump set-up KL 20
 Only for information
Suction Pump
Hopper Pump
A Drive Unit
1 Bearing Chair
2 Sealing Unit
3 Joint (by Hopper Pump with Feed Screw)
4 Suction Housing / Hopper Housing
5 Pump Set (Rotor/Stator)
6 Discharge Nozzle
