THE PARTS
The Waring WFP11SW and WFP14SW batch processors both
consist of the following standard parts and accessories:
1. Solid motor base with vertical heavy-duty shaft
2. Two control levers
a. ON
b. OFF/PULSE
3. Safety interlock (not shown)
Prevents machine from operating until cover is in place
4. Sealed clear work bowl
Dry capacity of 2.5 quarts for WFP11SW
Dry capacity of 3.5 quarts for WFP14SW
5. Sealed work bowl cover with feed chute cap
6. Sealed S-blade (cutter blade) to chop, grind, purée and mix
7. Sealed whipping disc
WFP11SW WFP14SW
4
5
6
1
2b2a
2b
7
2a
