WARN INDUSTRIES PAGE 3 80551A2
©2009 Warn Industries, Inc.
WARN® and the WARN logo are trademarks of Warn Industries Inc.
V. PARTS LIST
Ref Description Qty
A1 Plow Mount 1
A2 RH Locate Bracket 1
A3 LH Locate Bracket 1
A4 Plow Jogged RH 1
A5 Plow Jogged LH 1
B1 Plow Retaining Pin 2
B2 5/16 x 1 3/8 U-Bolt 2
B3 5/16 x 1 1/2 U-Bolt 2
B4 5/16 Flat Washers 8
B5 5/16 Lock Nut 8
B6 3/8 Flat Washer 2
B7 M10-1.25 x 30 mm Hex Bolt 2
B8 1/4-20 Hex Head Bolt 4
B9 1/4-20 Flat Washer 8
B10 1/4-20 Lock Nut 4
B11 Nut Clip 2
