INSTALLATION INSTRUCTIONS
Figure 7- Right Side with one of two carriage bolts attached
Figure 8
Figure 9
5. Position the strap over the vehicle frame as shown and
attach it to the plate with the two anged M8 bolts (A3) and
locking nuts (A2) provided. See Figures 8 and 9.
Note: Be sure to position the fasteners with threads up.
To Next Page
