Warn 92332 - INSTALLATION INSTRUCTIONS; Installing Fairlead Bracket

©2013 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 4 92334A0
INSTALLATION INSTRUCTIONS
Installing Fairlead Bracket
1. Remove the two upper 10mm screws and two lower torx
head screws holding small grille plate in place.
Remove small grille plate completely.
NOTE: Removing the full grille piece may allow for easier install.
2. Place fairlead bracket in place. Insert the two 12mm hex
head bolts in upper bracket holes and secure loosely. Next,
insert the two 8mm bolts in lower holes and secure loosely.
4. Tighten hardware now to torque specications listed on
page 2.
5. Using the two center holes in fairlead bracket. Install
fairlead, per winch kit instructions.
NOTE: Fairlead and fairlead hardware are found in winch kit.
Fairlead Bracket
Fairlead Installed
