Install Winch Mount Bracket
NOTE: For clarity, some pictures are shown with full grille
removed.
1. Unplug dierential tube and push aside to allow room for
winch mount placement.
2. Carefully slide winch mount bracket inbetween right a-arms
(left facing front of vehicle) and rest mount on top of
dierential.
3. Install two 10mm carriage bolts through winch mount upper
holes and frame of vehicle. Hand tighten only at this time.
4. Install two 10mm hex head bolts through front (a-arm
support and the inner lower winch mounting plate holes.
5. Tighten all hardware at this time.
Re-install dierential hose.
Dierential tube
Winch mount
Dierential
