Warren Controls 2800 Series - PARTS KITS; Repack Kits for 28 N Models

11
Series 2800 2800_IOM_RevBa_1219
PARTS KITS
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE T V-RING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 RETAINER BEARING 7 1 PACKING SPRING
3 1 PACKING RETAINER 8 1 O-RING RETAINER
5 1 V-RING PACKING SET 9 1 O-RING
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE T V-RING
SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
3 1 O-RING 7 1 V-RING PACKING SET
4 1 O-RING RETAINER 9 1 RETAINER BEARING
5 1 SPRING 10 1 PACKING RETAINER
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE G GRAPHITE
SEE DWG C3769952
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 PACKING RETAINER 5 1 PACKING CARTRIDGE
3 1 RETAINER BEARING 8 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE G GRAPHITE
SEE DWG C3760955
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
3 1 PACKING CARTRIDGE 6 1 PACKING RETAINER
5 1 RETAINER BEARING 8 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE V VACUUM SERVICE
SEE DWG C3761956
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 PACKING RETAINER 8 1 PACKING SPRING
3 1 RETAINER BEARING 9 1 O-RING RETAINER
5 1 MALE ADAPTER 10 1 O-RING
6 1 V-RING PACKING SET 13 1 TUBE STEM LUBE
7 1 FEMALE ADAPTER
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE V VACUUM SERVICE
SEE DWG C3760961
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 Packing Retainer 8 1 Spring
3 1 Retainer Bearing 9 1 O-Ring Retainer
5 1 Male Adapter 10 1 O-Ring
6 1 V-Ring Packing Set 13 1 Tube Stem Lube
7 1 Female Adapter
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & TYPE L LIP PACKING
SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 RETAINER BEARING 5 3 LIP PACKING
3 1 PACKING RETAINER 8 1 TUBE STEM LUBE
