5
Series 2800 2800_IOM_RevBa_1219
PART NUMBER & SERIAL NUMBER
Information Symbol(s) Location Notes
Part number
(Configuration)
P/N On actuator • On Actuator Nameplate attached to leg(s) of actuator.
Serial number S/N On actuator
and
valve body
• On Actuator Nameplate attached to leg(s) of actuator.
• Sales order Number only stamped on valve body end connection (2800).*
*Number stamped using approximately 1/8 inch tall characters
FLOW DIRECTION(S)
Information Symbol(s) Location Notes
Flow direction
through valve
On valve body • On 2800 S/S VBA Nameplate attached to mounting boss on valve body
between the end conections (2800 S/S valves ½ thru 1 inch except S/S 2832).
• Arrow cast on valve body between the end connections (2800 S/S 2-way 1-1/4 thru 2
inch).
Inlet location INLET On valve body • Stamped on valve body inlet end connection (2-way 2800 bronze valves ½ thru 2 inch &
S/S valves 1-1/4 thru 2 inch).
Port locations
for 3-way valves
U upper port,
L lower port,
C common
port
On valve body • U, L, & C stamped on valve body end connections (3-way 2800 bronze valves ½ thru 2
inch & 3-way 2800 S/S valves 1-1/4 thru 2 inch & 1 inch S/S 2832).
INPUT SIGNAL & SUPPLY
Information Symbol(s) Location Notes
Input signal SIG On actuator • On Actuator Nameplate attached to leg(s) of actuator.
Supply pressure SUP or
SUPPLY
On actuator • On Actuator Nameplate attached to leg(s) of actuator.
VALVE ATTRIBUTES
Information Symbol(s) Location Notes
Maximum
temperature rating
of valve body
TMAX or
Tmax
On actuator
and
valve body
• On Actuator Nameplate attached to leg(s) of actuator.
• On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-1/4
thru 2 inch, & 1 inch except S/S 2832).
• On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except
1 inch S/S 2832).
Trim Cv
(Flow coefficient)
Cv On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-1/4
thru 2 inch, & 1 inch S/S 2832).
• On 2800 S/S VBA Nameplate attached to valve body between the end connections on
side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except 1 inch S/S 2832).
Trim style
(Characteristic)
CHAR On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate. (2800 bronze valves ½ thru 2 inch & 2800 S/S valves
1-1/4 thru 2, & 1 inch S/S 2832).
Trim material TRIM MATL On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate. (2800 bronze valves ½ thru 2 inch & 2800 S/S valves
1-1/4 thru 2 inch, & 1 inch S/S 2832).
Valve size SIZE On valve body • On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except
1 inch S/S 2832).
Valve body material On valve body • If CF8M is cast on the valve the valve body material is 316 stainless steel.
INFORMATION PRESENT ON CONTROL VALVE
